Exports 64 TEFC IP55 VHS motors NEMA standards to the United States

Ultra-high efficiency vhs motors are exported to Europe, Mexico, the United States and other European and American countries: 60HZ/230V/440V/460VNEMA/F/IP23/dark gray/working altitude of 1000-2000 meters, NEMA standard WP-1 ODP
Note: Anti-reverse ball type, BD and BX size can be produced as needed, but if you do not provide the size, we will produce according to our catalog.
Packing: Plywood Shipment: Shipping.

vertical motor

No.	horsepower	speed	Model	SF 1.15	energy efficiency rating	Protection level
No.	HP	Speed	Model match	SF 1.15	Eff.%	Protection
1	7.5	1760	VHS215-4-07.5P	1.15	0.93	WP-1 ODP TEFC
2	10	1750	VHS215-4-010p	1.15	0.93
3	15	1760	VHS254TP-4-015P	1.15	0.93
4	20	1760	VHS256TP-4-020p	1.15	0.93
5	25	1760	VHS284TP-4-025P	1.15	0.94
6	30	1755	VHS286TP-4-030P	1.15	0.94
7	40	1775	VHS324TP-4-040P	1.15	0.94
8	50	1770	VHS326TP-4-050P	1.15	0.95
9	60	1775	VHS364TP-4-060P	1.15	0.95
10	75	1775	VHS365TP-4-075P	1.15	0.95
11	100	1765	VHS404TP-4-100P	1.15	95.40
12	125	1775	VHS405TP-4-125P	1.15	95.40
13	150	1780	VHS444TP-4-150P	1.15	95.80
14	175	1780	VHS444TP-4-175P	1.15	95.80
15	200	1780	VHS445TP-4-200P	1.15	95.80
16	250	1800	VHS445TP-4-250P	1.15	95.80
	270	1800		1.15	95.80
17	300	1800	VHS447TP-4-300P	1.15	95.80
18	300	1800	VHS5006TP-4-300P	1.15	95.80
19	350	1800	VHS5006TP-4-350P	1.15	95.80
20	400	1800	VHS5008TP-4-400P	1.15	95.80
96.2	450	1800	VHS5008TP-4-450P	1.15	96.20
22	500	1800	VHS5008TP-4-500P	1.15	96.20
23	700	1800	VHS5806TP-4-700P	1.15	96.20
